Engineering Graphics & BED part 2
Engineering Graphics (EG)
basic engineering drawing (BED)
Q.
1 When a surface of an object is
inclined to a plane of projection, it will appear _________________ in the
view.
(A) fore shortened (B) in true size and shape (C) as a line (D) as a point
ans
A
Q.
2 A sphere can be described in how many
views?
(A) 4
(B) 3 (C) 2 (D) 1
ans
D
Q.
3 If point C is below HP and behind VP
then in which quadrant point C lies?
(A) First
(B) Second (C) Third (D) Fourth
ans
C
Q.
4 A cone base diameter 40 mm and axis 60
mm is cut by a plane parallel to the base then the true shape will be
(A) Parabola
(B) Circle (C) Isosceles
Triangle (D) Regular Triangle
ans
B
Q.
5 The angle between each axis for an
isometric drawing is ____.
(A) 90 degrees (B) 120 degrees (C) 180 degrees (D) 60 degrees
ans
B
Q.
6 Representative fraction is ratio of
(A) Maximum length/Minimum length (B) Actual length of object/Length of
object in drawing (C) Length of object
in drawing/Actual length of object (D)
All of these
ans
C
Q.
7 Scale used when the lengths are
required in three consecutive units is
(A) Plain
(B) Vertical (C) Diagonal (D) Vernier
ans
C
Q.
8 In first angle projection system, plan
is drawn
(A) Above Elevation (B) Below Elevation (C) Left of the Elevation (D) Right of the Elevation
ans
B
Q.
9 Dashed line is used to draw…
(A) Outer Edges (B) Projections (C) Center & Center axis (D) Hidden faces
ans
D
Q.
10 A solid is said to be a right solid
if
(A) Axis is perpendicular to its base (B) Parallel to its base (C) Inclined to its base (D) All of these
ans A
Q.
11 If the value of Eccentricity is
greater than 1 curve will be
(A) Ellipse
(B) Parabola (C) Hyperbola (D) Circle
ans
C
Q.
12 The curve traced out by a point which
moves uniformly both about the centre and at the same time away or toward the
centre is
(A) Cycloid
(B) Logarithmic Spiral (C)
Involute (D) Archemedian Spiral
ans
D
Q.
13 When a line is inclined to VP and
parallel to HP, the front view will be _______ to xy
(A) parallel
(B) perpendicular (C) inclined
at angle f (D) non on these
ans
A
Q.
14 Second angle projection is not used
because
(A) Plan is above xy (B) both views overlap each other (C) elevation is above xy (D) views are small in size
ans
B
Q.
1 When a cone is cut by a plane
perpendicular to base passing through the apex “the shape of section obtained
is
(A) ellipse
(B) parabola (C) hyperbola (D) triangle
ans
D
Q.
2 In the third angle projection method,
the view seen from left is placed on
(A) Left of the Front View (B) Right of Front View (C) Right of Top View (D) Below Front View
ans
B
Q.
3 A French curve is used to draw
(A) Circles
(B) Ellipses (C) Smooth
curves (D) Polygon
ans
C
Q.
4 When the diameter of the directing
circle is twice the diameter of rolling circle the hypo cycloid obtained is a
(A) Circle
(B) Straight line (C)
Parabola (D) Hyperbola
ans
B
Q.
5 To obtain the true shape of the
section of solid, an auxiliary plane is set
(A) Inclined at an angle of 45o to a cutting
plane (B) parallel to XY (C) Parallel to a cutting plane (D) perpendicular to a cutting plane
ans
C
Q.
6 A square plate of negligible thickness
is inclined to HP and parallel to V.P. The front view will appear as
(A) rhombus
(B) square (C) line (D) rectangle
ans
C
Q.
7 Length of a line ‘L’ in isometric
drawing or view will be
(A) 0.707 L
(B) 0.815 L (C) 0.866 L (D) equal to length L
ans
D
Q. 8
The angle between isometric axis is
(A) 30º
(B) 90º (C) 120º (D) 180º
ans
C
Q.
9 Which one of the following is not a
reduction scale ?
(A) 1:1
(B) 1:200 (C) 5/320 (D) 5:6
ans
A
Q.
10 When a line is inclined to VP and
parallel to HP, the front view will be _______ to xy.
(A) parallel
(B) perpendicular (C) inclined
at angle f (D) none of the above
ans
A
Q.
11 While drawing the isometric view of
the sphere, its diameter is taken as
(A) Equal to actual diameter (B) 11/9 times of the actual diameter (C) 21/9 times of the actual diameter (D) none of the above
ans
B
Q.
12 The isometric view of a vertical line
is represented at an angle of ____ in front view and having a length _________
the original length of line.
(A) 30º, Same as (B) 30º, Less than (C) 90º, Same as (D) 90º, Less than
ans
C
Q.
13 When the cone, resting on base on
V.P., is cut by section plane parallel to V.P. then the true shape is
__________ and can be seen in __________ view.
(A) Circle, Front (B) Ellipse, Front (C) Ellipse, Top (D) Circle, Top
ans
A
Q.
14 For the third angle projection
method, Which of the following is correct?
(A) Observer - Object – Plane (B) Observer – Plane – Object (C) (a) and (b) both (D) None of above
ans
B
Q.
1 When the plane cuts the cone parallel
to one of the generator, the curve trace out by section is
(A) Ellipse
(B) Parabola (C) Hyperbola (D) Involute
ans
B
Q.
2 In first angle projection method The
Left hand side view is placed on
A)
Above elevation (B) Right side of
elevation (C) below elevation (D) Left side of elevation
ans
B
Q.
3 A French curve is used to draw
(A) Circles
(B) Smooth freeform curve (C)
Right circular cone (D) orthographic
projection
ans
B
Q.
4 If line is inclined to vertical plane
and parallel to Horizontal plane, then which one of the following is always
correct?
(A) True length = Plan length (B) True length = Elevation length (C) True length ? Plan length (D) None of the above
ans
A
Q.
5 To obtain the true shape of the
section of solid, an auxiliary plane is set at
(A) Parallel to cutting plane (B) Perpendicular to cutting plane (C) Parallel to Ground plane (D) Perpendicular to XY Plane
ans
A
Q.
6 A square plane is inclined to HP &
perpendicular to VP its elevation appears as
(A) Rhombus
(B) Square (C) Straight
line (D) Rectangle
ans
C
Q.
7 Length (L) of line in Isometric view
will be equal to
(A) 0.707 L
(B) 0.815 L (C) True length
L (D) 0.866 L
ans
C
Q.
8 For scale, which one is not correct
(A) 1:2
(B) 1:20 (C) 1:1/2 (D) 1/2
ans
D
Q.
9 In Isometric view length, Width, and
Height are inclined at
(A) 30º
(B) 60º (C) 90º (D) 120º
ans
D
Q.
10 When a point is below HP & in
Front of VP it is in
(A) First quadrant (B) Second quadrant (C) Third quadrant (D) Fourth quadrant
ans
D
Q.
11 In orthographic view the lines
Perpendicular to arrow X are drawn as (1) Parallel to XY in Plan (2) Parallel
to XY in elevation (3) Perpendicular to XY in Elevation
(A) 1
(B) 2 (C) 3 (D) 1 & 2
ans
D
Q.
12 When the cone, resting on base on
V.P., is cut by section plane parallel to V.P. then the true shape is
__________ and can be seen in __________ view.
(A) Circle, Front (B) Ellipse, Front (C) Ellipse, Top (D) Circle, Top
ans A
Q.
13 The isometric view of a vertical line
is represented at an angle of ____ in front view and having a length _________
the original length of line.
(A) 30º, Same as (B) 30º, Less than (C) 90º, Same as (D) 90º, Less than
ans
C
Q.
14 While drawing the isometric view of
the sphere, its diameter is taken as
(A) Equal to actual diameter (B) 11/9 times of the actual diameter (C) 21/9 times of the actual diameter (D) none of the above
ans
B
